400–1700 nm | Sony SenSWIR InGaAs | USB3/GigE | Uncooled | Short-Wave Infrared Cameras
Product Introduction
The uncooled SWIR 400–1700 nm series cameras feature Sony original SenSWIR InGaAs CMOS sensors with compact design, high heat dissipation efficiency, and low maintenance costs. Supporting USB3.0 and GigE high-speed data interfaces for easy integration into various industrial and research systems. Products cover the 400–1700 nm spectrum, suitable for online inspection, sorting equipment, mobile terminals, educational research, and other scenarios requiring imaging performance with limited budgets. Supporting multiple trigger modes and rich I/O interfaces, compatible with mainstream development environments, meeting batch deployment and OEM customization requirements.
Product Features
- 400–1800 nm response range, using Sony SenSWIR InGaAs sensors
- Precise temperature control, temperature difference up to -10 to -25 °C from ambient
- 5 µm pixel size, global shutter support
- USB3.0 interface support, future expansion to GigE, MIPI, CameraLink
- 12-bit ADC
- 4 Gb memory
- External I/O trigger control support
- High frame rates exceeding official specifications
- Field firmware upgrade support
- Dimensions 33 × 33 × 38 mm, weight approximately 70 g
Product Models
Choose the best 400–1700 nm | Sony SenSWIR InGaAs | USB3/GigE | Uncooled | Short-Wave Infrared Cameras model for your application needs
| Model | Sensor | Resolution | Pixel Size | Frame Rate | Data Interface | Dynamic Range | Action |
|---|---|---|---|---|---|---|---|
| SWIR5000KMB-UMV |
Sony IMX992-AABJ-C (InGaAs)
8.94 mm × 7.09 mm
|
5.0 MP (2560×2048) | 3.45 µm × 3.45 µm |
61.9 fps@2560×2048
135.7 fps@1280×1024
|
USB3 |
51.36 dB (HCG); 51.47 dB (LCG)
|
View Details |
| SWIR5000KMB-GMV |
Sony IMX992-AABJ-C (InGaAs)
8.94 mm × 7.09 mm
|
5.0 MP (2560×2048) | 3.45 µm × 3.45 µm |
22 fps@2560×2048
11 fps@2560×2048 (12-bit)
|
GigE |
51.36 dB (HCG); 51.47 dB (LCG)
|
View Details |
| SWIR3000KMB-UMV |
Sony IMX993-AABJ-C (InGaAs)
7.07 mm × 5.3 mm
|
3.0 MP (2048×1536) | 3.45 µm × 3.45 µm |
93 fps@2048×1536
176 fps@1024×768
|
USB3 |
51.36 dB (HCG); 51.47 dB (LCG)
|
View Details |
| SWIR3000KMB-GMV |
Sony IMX993-AABJ-C (InGaAs)
7.07 mm × 5.30 mm
|
3.0 MP (2048×1536) | 3.45 µm × 3.45 µm |
37 fps@2048×1536
18.5 fps@2048×1536 (12-bit)
|
GigE |
51.36 dB (HCG); 51.47 dB (LCG)
|
View Details |
| SWIR330KMB-UMV |
Sony IMX991-AABJ-C (InGaAs)
3.20 mm × 2.56 mm
|
0.33 MP (640×512) | 5.0 µm × 5.0 µm |
428.1 fps@640×512
807 fps@320×256
|
USB3 |
59.6 dB
|
View Details |
| SWIR330KMB-GMV |
Sony IMX991-AABJ-C (InGaAs)
3.20 mm × 2.56 mm
|
0.33 MP (640×512) | 5.0 µm × 5.0 µm |
257.8 fps@640×512
137.1 fps@640×512 (12-bit)
|
GigE |
59.6 dB
|
View Details |
| SWIR1300KMB-UMV |
Sony IMX990-AABJ-C (InGaAs)
6.40 mm × 5.12 mm
|
1.3 MP (1280×1024) | 5.0 µm × 5.0 µm |
223 fps@1280×1024
428 fps@640×512
|
USB3 |
58.7 dB
|
View Details |
| SWIR1300KMB-GMV |
Sony IMX990-AABJ-C (InGaAs)
6.40 mm × 5.12 mm
|
1.3 MP (1280×1024) | 5.0 µm × 5.0 µm |
90 fps@1280×1024
45 fps@1280×1024 (12-bit)
|
GigE |
58.7 dB
|
View Details |
Frequently Asked Questions
Learn more about SWIR short-wave infrared camera technology
Deep Understanding of SWIR Cameras
Short-Wave Infrared (SWIR) cameras and their core sensors are important components of advanced imaging systems. SWIR technology covers the 900~1700 nanometer wavelength band and has excellent penetration capabilities in harsh environments, such as penetrating fog, smoke, and dust to achieve clear imaging under extreme conditions.
SWIR cameras primarily rely on short-wave infrared light reflection, similar to the visible light band, complementing the application range that thermal imaging cameras (LWIR) cannot cover, providing more complete imaging solutions. They are compact and flexibly integrated, making them easy to apply in various industrial and commercial systems.
The high resolution and high sensitivity of SWIR cameras can meet precision detection and high-requirement applications, capable of detecting minute changes and anomalies in samples, making them very suitable for quality control and defect detection. Some models support cooling, further ensuring imaging quality in high-temperature or high-noise environments.
To reduce system costs and improve integration efficiency, modern SWIR cameras commonly adopt standard optical interfaces and compact designs to accommodate broader application requirements. With the continuous development of imaging markets and technology, SWIR cameras have become one of the key technologies for high-end imaging and sensing in multiple industries due to their unique advantages.
Application Examples
Demonstration of SWIR camera applications in real-world scenarios
More Application Industry References
- Semiconductor Industry: Solar cell and chip inspection
- Agriculture: Spectral remote sensing applications via multirotor aircraft
- Recycling Industry: Material sorting of plastics, waste, and other materials
- Medical Imaging and Research: Hyperspectral and multispectral imaging
- Food Industry: Quality inspection and grading
- Beverage Industry: Liquid level detection in opaque containers
- Packaging: Seal inspection
- Glass Industry: High-temperature glass penetration defect detection
- Printing Industry: See-through hidden features
- Video Surveillance: Visual enhancement (e.g., smoke penetration)
- Security: Counterfeit detection, such as currency, wigs, or skin
