WCAM0300KPA C-Mount Wi-Fi CMOS-Kamera
Product Introduction
WCAM0300KPA is a high-performance C-Mount Wi-Fi CMOS-Kamera featuring Aptina MT9V011(C) sensor, with resolution up to 0.3MP (640×480), supporting Wi-Fi 802.11n multiple output methods.
Product Features
- Wi-Fi-Drahtlosübertragung
- Mehrgeräteverbindung
- ROI-Weißabgleich
- Manuelle Belichtungssteuerung
- Wirtschaftliche Lösung
Product Details
WCAM0300KPA Specifications
| Key Parameters | |
| Product Model | WCAM0300KPA |
| Product Series | C-Mount Wi-Fi CMOS-Kamera |
| Sensor Parameters | |
| Sensor Model | Aptina MT9V011(C) |
| Sensor Size | 1/4" (3.58×2.69mm) |
| Diagonal | 4.5mm |
| Pixel Size | 5.6μm × 5.6μm |
| Resolution | 0.3MP (640×480) |
| Shutter Type | Rolling Shutter |
| Color Type | Farbe |
| Performance Parameters | |
| Frame Rate | Wi-Fi: 25fps@640×480 |
| Output Interfaces | Wi-Fi 802.11n |
| Lens Mount | C-Mount-Anschluss |
| Storage Support | Kein lokaler Speicher |
| Software Support | ToupView, ToupLite |
| Physical Parameters | |
| Power Supply | USB 5 V Stromversorgung |
| Dimensions | 50 × 50 × 92 mm |
| Weight | 0.2 kg |
| Environmental Parameters | |
| Operating Temperature | -10°C ~ +50°C |
| Other Information | |
| OS Support | Windows, Android, iOS |
| Certification | CE, FCC, RoHS |
Product Overview
WCAM0300KPA is a Wi-Fi-Drahtlosausgabe, Mehrgeräte-Fernverbindung, kompakte Bauweise, geeignet für Einsteiger-Mikroskopie und interaktiven Unterricht. designed for high-definition real-time imaging, featuring the following core capabilities:
- Plug-and-Play Design: Direct HDMI HD video output without a computer, ready for microscopy observation and recording with just a display
- USB Voice Control Module: Supports voice commands for real-time camera control, enabling hands-free photo capture, recording, freeze, and other operations
- Barcode Scanner Capture: Supports barcode scanner-triggered capture function, ideal for batch sample recording and traceability management
- Intelligent Measurement Functions: Built-in XCamView software supports auto edge detection, automatic parallel line distance measurement, automatic rectangle measurement, and other intelligent measurement features
- Local Storage and Comparison: Supports USB storage, local preview and playback, image comparison, video comparison functions for convenient sample analysis
- Powerful ISP Processing: Provides dark field enhancement, sharpening, and 3D noise reduction functions to significantly improve image quality
- Quick Scene Switching: Supports quick switching between biological microscope and stereo microscope default effects, adapting to multi-scene usage requirements
Core Performance Indicators
1080P
Video Resolution
30 fps
Maximum Frame Rate
Multi-Interface
HDMI/USB Output
0.3MP (640×480)
Sensor Resolution
Advanced Features
Voice Control
Voice operation through USB audio control module for improved convenience
Barcode Capture
Supports barcode scanner-triggered photography, ideal for batch sample management
Smart Measurement
Auto edge detection and measurement functions improve measurement efficiency and accuracy
ISP Optimization
Powerful image processing capability to optimize imaging quality
Why Choose This Product
WCAM0300KPA with its plug-and-play design concept, diverse control methods, and powerful image processing capabilities, is particularly suitable for microscopy observation scenarios requiring high-definition real-time display. The addition of voice control and barcode capture functions greatly improves operational efficiency, making it an ideal choice for teaching demonstrations, industrial inspection, and research recording applications.
Application Scenarios
Basis-Mikroskopbildgebung
Basis-Mikroskopbildgebung
Unterrichtsdemonstrationen
Unterrichtsdemonstrationen
Einfache Beobachtung
Einfache Beobachtung
Einstiegsanwendungen
Einstiegsanwendungen
Application Case Display
Einschichtiges Flimmerepithel
Einschichtiges kubisches Epithelschnitt
Lockeres Bindegewebspräparat
Faseriges Bindegewebe-Schnitt
Selection Guide
- 4K HD Requirements: Choose WCAM4K8MPA or WCAM4K8MPB, supporting 3840×2160 resolution
- High Frame Rate Requirements: Choose WCAM1080P series, supporting 60 fps high-speed imaging
- Large Target Surface Requirements: Choose IMX678 sensor model, 1/1.8" large target surface
- Budget-Friendly Option: Choose IMX415 or IMX462 sensor models for high cost-effectiveness
WCAM0300KPA Product Manual
PDF format, includes detailed technical specifications, dimension drawings, and application guide
Software Download
XCamView / ToupView / ToupLite professional imaging software
3D Model Files
STEP format, for system integration design
In-Depth Overview
The ToupTek Photonics WCAM series is a wireless Wi-Fi camera with a standard C-mount and high-performance CMOS image sensor, purpose-built for image and video capture on stereo and biological microscopes.
Its integrated Wi-Fi module streams high-resolution imaging signals to smartphones, tablets, and computers running iOS, Android, Windows, macOS, and other OS platforms, enabling up to six devices to connect simultaneously for teaching, interactive demonstrations, and multi-user sharing.
Technical Highlights
- Wireless multi-endpoint connectivity: Streams camera feeds over Wi-Fi to phones, tablets, and computers with up to six concurrent viewers.
- High-performance imaging and encoding: Uses an Aptina CMOS sensor with H.264 streaming to deliver sharp visuals and smooth video.
- Cross-platform compatibility: Works seamlessly with Windows, iOS, macOS, Linux, and Android environments.
- Professional imaging software support: Bundled ToupView software handles video reception, processing, and measurement for research and education.
- Rugged, low-noise design: Zinc-aluminum precision die-cast housing plus high-efficiency thermal layout keep long sessions stable and quiet.
Core Advantages
-
1
Wireless multi-device collaboration Simultaneous viewing across devices streamlines classroom demos, lab work, and group observations.
-
2
Efficient video encoding and streaming H.264 streams provide crisp imagery with low latency for teaching and research scenarios.
-
3
Cross-platform readiness Operates across diverse operating systems and hardware with strong compatibility.
-
4
Rugged design with stable performance Zinc-aluminum construction and optimized thermal paths ensure long-term stability.
-
5
Wide application coverage Supports Wi-Fi microscope cameras, C-mount HDMI cameras, shared microscope viewing, and interactive classroom microscopy.
