TPHD4K133D AM-OLED Hochwertige Standard-HDMI-Monitorserie (4K / 1080P)
Product Introduction
TPHD4K133D is a 13,3 Zoll AM-OLED display, with resolution up to 3840×2160 (4K), featuring 100000:1 ultra-high contrast ratio and 100% DCI-P3 wide color gamut, supporting HDR dynamic enhancement, providing excellent display effects for professional imaging.
Product Features
- 4K Ultra-HD AM-OLED, selbstleuchtend mit hohem Kontrast
- 100 % DCI-P3 breiter Farbraum, professionelle Wiedergabe
- Integrierter Klappständer, schnelle Einrichtung
- Integrierter Klappständer, Erweiterungs-/Split-Screen-Unterstützung
Product Details
TPHD4K133D Specifications
| Basic Parameters | |
| Product Model | TPHD4K133D |
| Display Type | Standard-Display |
| Panel Type | AM-OLED |
| Display Parameters | |
| Screen Size | 13,3 Zoll |
| Aspect Ratio | 16:9 |
| Resolution | 3840×2160 (4K) |
| Pixel Pitch | 0.0765×0.0765mm (332PPI) |
| Contrast Ratio | 100000:1 |
| Brightness | 400cd/m² |
| Color Gamut | 100% DCI-P3 |
| Color Depth | 1,07 Milliarden Farben |
| Viewing Angle | 178° IPS-Vollbetrachtungswinkel |
| Performance Parameters | |
| Refresh Rate | 60Hz |
| Response Time | 3ms |
| Backlight Type | LED-Hintergrundbeleuchtung (Lebensdauer 50000 Stunden) |
| Display Area | 293.76(H) × 165.24(V)mm |
| Physical Parameters | |
| Dimensions | 306×183×8mm |
| Weight | 560g |
| Border Width | 4 mm dreiseitiger schmaler Rahmen |
| Screen-to-Body Ratio | 81.5% |
| Power & Environment | |
| Power Consumption | Max. 15 W |
| Power Input | AC110V-220V/DC12V(1A) Type-C |
| Operating Temperature | -15°C~55°C |
| Operating Humidity | Betriebsfeuchte 10 % – 90 %, Lagerfeuchte 5 % – 90 % |
| Interface Information | |
| Input Interface | Standard-HDMI |
| Sync Range | Horizontal 30–80 kHz, Vertikal 55–75 Hz |
| Body Color | Schwarz |
Product Overview
TPHD4K133D as a professional display in Topograph Optoelectronics TPHD series, adopts advanced AM-OLED panel technology, providing excellent visual experience for scientific imaging, teaching demonstration and industrial inspection.
Core Technical Features
- 4K Ultra HD Resolution: 3840×2160 pixels, providing delicate and clear image details, suitable for precise observation and analysis
- AM-OLED Self-Illuminating Technology: 100000:1 ultra-high contrast ratio, perfect black field performance, clear image layering
- 100% DCI-P3 Wide Color Gamut: Professional-grade color reproduction, ensuring imaging color accuracy
- HDR Dynamic Enhancement: Extended dynamic range, clear presentation of both dark details and highlights
- 3 ms Fast Response: Low latency display, smooth dynamic images without ghosting
- Slim and Portable Design: Narrow bezels and folding stand, convenient for laboratory and field deployment
- Standard HDMI Interface: Plug and play, compatible with various imaging devices and signal sources
Display Performance Indicators
3840×2160 (4K)
Resolution
400cd/m²
Brightness
100% DCI-P3
Color Gamut Coverage
3ms
Response Time
Design Features
Slim and Portable
Only 8 mm thick, 560 g weight, easy to carry and deploy
Narrow Bezel Design
Three-sided narrow bezels, screen-to-body ratio over 81.5%, strong visual immersion
Plug and Play
Standard HDMI interface, no complex setup required, connect and use immediately
Eye Protection Technology
Low blue light, flicker-free design, reduces eye fatigue during extended viewing
Recommended Reasons
TPHD4K133D with its ultra-high definition 4K resolution, AM-OLED self-illuminating technology and 100% DCI-P3 wide color gamut, combined with HDR dynamic enhancement and 3 ms fast response, provides a high cost-effective display solution for professional users. The slim portable design and plug-and-play convenience make it an ideal choice for scientific imaging, teaching demonstration and industrial inspection.
Application Scenarios
Scientific Imaging
Microscope imaging, experimental data display, image analysis and processing
Teaching Demonstration
Classroom teaching display, experiment demonstration, academic report presentation
Industrial Inspection
Product quality testing, defect analysis, precision measurement display
Medical Imaging
Medical image viewing, pathological analysis, surgical monitoring
Design & Drawing
CAD drawing, 3D modeling, color calibration
Video Monitoring
Real-time monitoring display, recording playback, multi-screen display
Selection Guide
- High Precision Requirements: Choose TPHD4K133D, 4K resolution with 100% DCI-P3 color gamut, suitable for professional imaging
- Portability Priority: Choose TPHD1080PD, 13.3-inch slim design, convenient for mobile use
- Large Screen Display: Choose TPHD1080P156A, 15.6-inch large field of view, suitable for multi-person viewing
- Budget Consideration: 1080P series offers high cost-effectiveness, meeting daily professional display needs
Compatibility Description
TPHD series displays equipped with standard HDMI interface, perfectly compatible with:
- Topograph Optoelectronics XCAM series HDMI cameras
- Various computers and workstations
- Set-top boxes, players and other multimedia devices
- Signal generators, oscilloscopes and other test equipment
- Medical imaging devices, industrial cameras and other professional equipment
TPHD4K133D Product Manual
PDF format, including detailed technical specifications, dimension drawings and user guide
TPHD Standard HDMI Display Series — Product Introduction
Topograph Optoelectronics TPHD Standard HDMI Display Series focuses on non-touch series with pure display performance, covering 13.3-inch 4K AM-OLED and 13.3/15.6-inch 1080P IPS models.
High contrast ratio, wide color gamut and low latency provide stable and reliable output for scientific observation, industrial testing and teaching demonstration. Combined with slim portable design and standard HDMI interface, achieving rapid deployment and plug-and-play functionality.
In-depth Introduction
TPHD Standard HDMI Display Series (4K AM-OLED / 1080P IPS)
-
Full Coverage of 4K AM-OLED and 1080P IPS:
The series provides 13.3″ 4K AM-OLED and 13.3/15.6″ 1080P IPS multiple specifications, meeting different needs from portable demonstration to desktop display. -
High Contrast, Wide Color Gamut and Ultra-Fast Response:
4K models feature 100000:1 contrast ratio and 100% DCI-P3 wide color gamut; full series supports HDR dynamic enhancement and 3 ms level fast response. -
Wide Viewing Angle and Stable Grayscale:
Based on 178° wide viewing angle panel, maintaining color and grayscale consistency during multi-person viewing and classroom teaching even from side angles. -
Slim Portable and Plug-and-Play:
Slim narrow bezel design with integrated folding stand, standard HDMI input, convenient for rapid deployment.
Core Advantages
4K AM-OLED High Contrast
TPHD4K133D: 100000:1 contrast ratio, 100% DCI-P3 wide color gamut
1080P IPS Universal Choice
13.3″/15.6″ multiple sizes available, portable or large field of view as needed
HDR and 3 ms Response
Dynamic enhancement and low ghosting, suitable for preview, demonstration and testing
178° Wide Viewing Angle
Color and grayscale remain stable when viewed from the side during multi-person viewing
Slim Portable · Plug and Play
Narrow bezel and folding stand design, standard HDMI connection ready to use out of the box
