AVCAM Series

Product Introduction

The AVCAM Series is designed for retrofit and legacy system integration scenarios requiring analog video signals. It features the Sony IMX307 (1/2.8″, 2.9 µm) sensor and outputs standard format video signals via CVBS (PAL), equivalent to 720×576 @ 25 fps, enabling direct connection to traditional monitors, recorders, and capture cards. The compact form factor with M12 lens mount offers flexible installation, suitable for embedding in complete systems or confined spaces.

The camera employs a rolling shutter and supports exposure range from approximately 105 µs to 20 ms with 1×1/2×2/3×3 hardware binning to balance brightness, resolution, and frame rate. Powered via USB2.0 port (also available for parameter configuration, model-dependent), it operates reliably in cable-restricted or mobile power scenarios. Supporting software and SDK (model-dependent) are provided for remote configuration of gain, exposure, ROI, and system integration.

Product Features

Sensor: Sony IMX307, 1/2.8″ format, 2.9 µm pixel, low noise and high sensitivity
Video output: CVBS (PAL format), equivalent to 720×576 @ 25 fps, compatible with traditional display/capture devices
Shutter: Rolling shutter, minimizes smearing and flickering (depending on light source frequency)
Exposure and gain: approximately 105 µs–20 ms; supports auto/manual exposure and manual gain (model-dependent)
Hardware binning: 1×1/2×2/3×3, enabling flexible trade-offs between brightness, resolution, and frame rate
ROI (Region of Interest): supports configuration and dedicated auto-adjust ROI (model-dependent)

Interface and power: USB2.0 powered; CVBS video output (BNC/AV port, model-dependent)
Lens mount: M12 (S-mount), compact size for easy integration and installation
Synchronization and status: Trigger Ready/Input/Exposure/Readout/Imaging/Strobe/GPO signals (model-dependent)
Image pipeline: LUT, Gamma, bandwidth control, image buffer/cache, defective pixel correction (model-dependent)
Software and development: includes ToupView and SDK (Windows/Linux/macOS/Android, model-dependent) for secondary development
Reliability: CE/FCC compliant (model-dependent), suitable for global market deployment

Get Quote Product Manual

Product Models

Select the AVCAM Series that fits your application requirements

Product Model	Effective Pixels	Sensor Size	Shutter Type	Frame Rate (FPS)	Sensor Type	Data Interface	Color	Actions
AVCAM290A	0.4 MP (720×576)	2.08 mm × 1.67 mm 1/6" (2.67 mm)	Rolling Shutter	25 fps @ 720×576	Sony IMX307	CVBS (PAL-N format)		View Details

Package List #

Standard configuration and box contents for AVCAM Series compact industrial cameras (USB 3.0)

Recommended Accessories

Camera body – AVCAM Series model
USB 3.0 cable – Type-C to Type-A cable
Lens (optional) – CS-mount lens

Note: The AVCAM Series adopts a compact design and runs directly on USB power without external power supplies.

Standard package list; refer to the packing slip for final accessories

Product Dimensions #

Dimensions overview for AVCAM Series compact industrial cameras

AVCAM Series

Compact Dimensions diagram

29 mm ultra-compact design

Click the image to view a larger version

The AVCAM Series is Tupu Photonics' lineup of analog video industrial cameras built around high-sensitivity Sony CMOS sensors. They deliver CVBS (PAL-N standard) video output for real-time monitoring, industrial inspection, and low-bandwidth transmission. Their compact structure, streamlined interfaces, and strong compatibility make them ideal for legacy video interfaces and applications with relaxed latency requirements.

Key Features

Analog video output

CVBS (PAL-N) standard signal

Sony CMOS sensor

IMX307 high-sensitivity sensor

Real-time video output

25 fps stable output with low latency

Plug-and-play design

USB 2.0 power for simplified deployment

Performance Highlights

Frame rate

25 fps

@ 720×576

Sensor size

1/2.8"

2.9 µm pixels

Gain range

1–100×

Flexible adjustment

Compact size

45×58.5 mm

Compact body

In-depth Product Overview

High-sensitivity sensor design

Equipped with the Sony IMX307 1/2.8" rolling shutter CMOS sensor featuring 2.9 µm square pixels, low noise, and excellent light adaptability. The 400,000-pixel configuration preserves image quality while optimizing video transmission efficiency. The high-sensitivity architecture maintains clear output in low-light environments, making it well suited for industrial monitoring and inspection.

Standard analog video interface

Supports the CVBS (PAL-N) standard for direct analog video output, enabling seamless integration with legacy surveillance and display equipment. The stable 25 fps @ 720×576 stream ensures smooth real-time video. The design connects to existing analog systems without extra encoding, greatly reducing upgrade costs.

Intelligent imaging controls

Adjustable gain from 1–100× and exposure from 105 µs to 20 ms provide flexibility across lighting conditions. Built-in 1×1, 2×2, and 3×3 hardware binning allows optimization among resolution, frame rate, and sensitivity according to application needs. The rolling shutter (RS) architecture balances real-time image quality with system compatibility.

Compact and reliable industrial build

A 45×58.5 mm compact metal body with USB 2.0 power minimizes deployment complexity through single-cable connectivity. Operating temperatures range from -10 to 50 °C with 20%–80% relative humidity (non-condensing), ensuring long-term stability across industrial environments. CE and FCC certifications meet international standards, ideal for low-latency monitoring and inspection.

Comprehensive software ecosystem

Compatible with ToupView software and supports Windows, Linux, macOS, and Android development. The SDK delivers C/C++, C#/VB.NET, Python, Java, DirectShow, and TWAIN interfaces for secondary development. This complete software stack helps integrate the cameras into existing systems quickly while addressing custom requirements.
