ToupTek Photonics' microscopy camera reigns supreme as the most exemplary digital camera for laboratory microscopy apparatus. By integrating a microscopy camera into the user's existing microscopy infrastructure, it enables the acquisition of images or videos for further refinement and dissemination.
For the procurement of microscope cameras, a premium-quality microscope adapter is essential for capturing pristine high-definition digital images via the microscope. ToupTek Photonics has crafted an array of adapters suitable for interfacing with microscope tubes, microscope tees, or eyepiece tubes. The microscopes that can be adapted encompass those from four prominent global brands—Zeiss, Nikon, Leica, and Olympus—as well as esteemed Chinese microscope producers. The microscope cameras and accompanying software from ToupTek Photonics deliver standardized, superior image and video capture and processing functionalities.
For all patrons desiring to transform a traditional microscope into a digital variant, ToupTek Photonics will assist in selecting and integrating the most fitting microscope camera tailored to their specific microscope model. ToupTek Photonics is committed to aiding each user in capturing professional-grade microscopic imagery, thereby enriching the experience of all who employ its products.
MTR3CCD Series
Order Code | Sensor & Size(mm) | Pixel(μm) |
G Sensitivity
Dark Signal |
FPS/Resolution | Binning | Exposure |
---|---|---|---|---|---|---|
MTR3CCD12000KPA |
12.0M/ICX834AQG(C)
1"(13.15x8.77) |
3.10x3.10 |
420mv with 1/30s
15.2mv with 1/30s |
3.6@4248x2836
3.6@2124x1418 |
1x1
2x2 |
0.06ms~1h |
MTR3CCD12000KMA |
12.0M/ICX834ALG(C)
1"(13.15x8.77) |
3.10x3.10 |
420mv with 1/30s
12mv with 1/30s (F8.0) |
3.6@4248x2836
3.6@2124x1418 |
1x1
2x2 |
0.06ms~1h |
MTR3CCD09000KPA |
9.0M/ICX814AQG(C)
1"(12.47x9.98) |
3.69x3.69 |
580mv with 1/30s
12mv with 1/30s |
4.4@3388x2712
4.4@1694x1356 |
1x1
2x2 |
0.06ms~1h |
MTR3CCD09000KMA |
9.0M/ICX814ALG(C)
1"(12.47x9.98) |
3.69x3.69 |
660mv with 1/30s
12mv with 1/30s (F8.0) |
4.4@3388x2712
4.4@1694x1356 |
1x1
2x2 |
0.06ms~1h |
MTR3CCD06000KPA |
6.0M/ICX694AQG(C)
1"(12.48x9.99) |
4.54x4.54 |
880mv with 1/30s
8mv with 1/30s |
7.5@2748x2200
14@2748x1092 |
1x1 | 0.06ms~1h |
MTR3CCD06000KMA |
6.0M/ICX694ALG(M)
1"(12.48x9.998) |
4.54x4.54 |
1000mv with 1/30s
8mv with 1/30s |
7.5@2748x2200
14@2748x1092 |
1x1 | 0.06ms~1h |
MTR3CCD02800KPA |
2.8M/ICX674AQG(C)
2/3"(8.81x6.63) |
4.54x4.54 |
800mv with 1/30s
4mv with 1/30s |
15@1938x1460
17@1610x1212 18@1930x1092 |
1x1 | 0.05ms~1h |
MTR3CCD02800KMA |
2.8M/ICX674ALG(M)
2/3"(8.81x6.63) |
4.54x4.54 |
950mv with 1/30s
4mv with 1/30s |
15@1938x1460
17@1610x1212 18@1930x1092 |
1x1 | 0.05ms~1h |
MTR3CCD01400KPA |
1.4M/ICX285AQA(C)
2/3"(8.88x6.70) |
6.45x6.45 |
1240mv with 1/30s
10mv with 1/30s |
15@1360x1024 | 1x1 | 0.07ms~1h |
MTR3CCD01400KMA |
1.4M/ICX285ALA(M)
2/3"(8.88x6.70) |
6.45x6.45 |
1300mv with 1/30s
11mv with 1/30s |
15@1360x1024 | 1x1 | 0.07ms~1h |
MTR3CCD01400KPB |
1.4M/ICX825AQA(C)
2/3"(8.88x6.70) |
6.45x6.45 |
2000mv with 1/30s
4.8mv with 1/30s |
25@1376x1040 | 1x1 | 0.07ms~1h |
MTR3CCD01400KMB |
1.4M/ICX825ALA(M)
2/3"(8.88x6.70) |
6.45x6.45 |
2000mv with 1/30s
4.8mv with 1/30s |
25@1376x1040 | 1x1 | 0.07ms~1h |
MTR3CCD
MTR3CCD Series Camera adopts Sony Exview HAD CCD II sensor as the image-picking device with two-stage peltier cooling sensor chip to -40 degree below ambient temperature. This will greatly increase the signal to noise ratio and decrease the image noise. Smart structure is designed to ensure the heat radiation efficiency and avoid the moisture problem. Electric fan is used to increase the heat radiation speed.
SCMOS
SCMOS series is an economic version with simple and compact structure CMOS eyepiece camera. So here, the S means simple and compact. USB2.0 is used as the data transfer interface.
